NAS Synology RS422+ RackStation 4-bay

SYNOLOGY
Šifra: 55376
Maloprodajna cena: 107.698,00 rsd.
WebCena: 95.732,00 rsd.
*Cena sa popustom važi za online kupovinu, kao i u prodavnici za plaćanje gotovinom, virmanom (preko računa) ili odmah debitnom karticom.
Broj rata
 Količina
Hardware Specifications
CPU
CPU ModelAMD Ryzen R1600
 CPU Quantity1
 CPU Core2
 CPU Architecture64-bit
 CPU Frequency2.6 (base) / 3.1 (turbo) GHz
 Hardware Encryption Engine
Memory
System Memory2 GB DDR4 ECC
 NotesSynology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays4
 Drive Type (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA SSD
 Hot Swappable Drive*
External Ports
RJ-45 1GbE LAN Port2
 USB 3.2 Gen 1 Port*1
 Notes
  • This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
  • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe
PCIe Expansion1 x Gen3 x2 network upgrade slot
Appearance
Form Factor (RU)1U
 Size (Height x Width x Depth)44 mm x 478 mm x 327.5 mm
 Weight4.38 kg
 Rack Installation Support*
  • 4-post 19" rack (Synology Rail Kit - RKM114/RKS-02)
  • 2-post 19" rack (direct mounting)
 NotesThe rail kit is sold separately
Others
System Fan40 mm x 40 mm x 3 pcs
 Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
 Power Recovery
 Noise Level*28.5 dB(A)
 Scheduled Power On / Off
 Wake on LAN / WAN
 Power Supply Unit / Adapter100 watts
 AC Input Power Voltage100V to 240V AC
 Power Frequency50/60 Hz, Single Phase
 Power Consumption37.93 watts (Access)
13.43 watts (HDD Hibernation)
 British Thermal Unit129.42 BTU/hr (Access)
45.83 BTU/hr (HDD Hibernation)
 Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle stae. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature0°C to 35°C (32°F to 95°F)
 Storage Temperature-20°C to 60°C (-5°F to 140°F)
 Relative Humidity5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
  • BIS
Warranty
3-year hardware warranty, extendable to 5 years with EW201 or Extended Warranty Plus
 Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
  • Extended Warranty Plus is only available in Europe and North America. EW201/EW202 is only available in Asia, Africa, and Oceania. For exact availability information please visit their respective websites.
Environment
RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • Quick Installation Guide X 1
Optional Accessories
 NotesCertain items may not be available in your location. Please contact your local distributors for more information.
DSM Specifications
Maximum Single Volume Size108 TB
 Maximum Internal Volume Number64
 SSD Read/Write Cache (Determining cache size)
 SSD TRIM
 Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
 RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
 Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
 Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • JBOD
  • RAID 5
 Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
 Notes
  • Usable capacity for each volume will be lower than the maximum volume size and is dependent on the filesystem and the amount of system metadata stored.
  • Actual maximum storage pool and volume sizes depend on drive sizes used, the number of drive bays available, and the RAID configuration.
Internal Drives
  • Btrfs
  • ext4
 External Drives
  • Btrfs
  • ext4
  • ext3
  • FAT
  • NTFS
  • HFS+
  • exFAT
File Protocol
  • SMB
  • AFP
  • NFS
  • FTP
  • WebDAV
  • Rsync
 Maximum Concurrent SMB/AFP/FTP Connections500
 Windows Access Control List (ACL) Integration
 NFS Kerberos Authentication
 NotesThe testing standard was based on the maximum number of concurrent connections supported by this model. During the testing, 25% of the connections were used to transfer files concurrently. The transfer process guaranteed that the connections were not interrupted; the minimum transfer speed was not guaranteed.
Maximum Local User Accounts2,048
 Maximum Local Groups256
 Maximum Shared Folder512
 Maximum Shared Folder Sync Tasks8
Maximum Hybrid Share Folders10
Folder and Package Backup
 Entire System Backup
 NotesFull-system backup requires DSM 7.2 or later.
Synology High Availability
Syslog Events per Second800
Supported ProtocolsSMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
 Supported Browsers
  • Chrome
  • Firefox
  • Edge
  • Safari
 Supported LanguageEnglish, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, ???????, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ???????, ???, ???, ????, ????
 NotesFor an updated list of supported browser versions, check the DSM Technical Specifications.

Suggested Users100
 Notes
  • Measured with simulated users, each with an average record of 20,000 messages, emojis, or stickers. The required server response time is below ten seconds.
  • Models with expandable memory are tested with their maximum supported memory.
Download Station
Maximum Concurrent Download Tasks80
Maximum iSCSI Target Number128
 Maximum LUN256
 LUN Clone/Snapshot, Windows ODX
DLNA Compliance
Facial Recognition
Maximum Snapshots per Shared Folder1,024
 Maximum of System Snapshots65,536
Default Licenses(Additional cameras require purchase of licenses)
 Suggested Maximum IP Cameras and Total FPS (H.264)
  • 1080p: 40 channels, 800 FPS
  • 3M: 35 channels, 350 FPS
  • 5M: 28 channels, 280 FPS
  • 4K: 17 channels, 170 FPS
 Suggested Maximum IP Cameras and Total FPS (H.265)
  • 1080p: 40 channels, 1200 FPS
  • 3M: 40 channels, 600 FPS
  • 5M: 40 channels, 480 FPS
  • 4K: 20 channels, 200 FPS
 Notes
  • Performance figures are obtained from testing conducted with the device fully populated with drives, with their default memory configuration, and under a continuous recording setup. Actual system capabilities may vary based on configuration, drive performance, enabled features, and the presence of additional workloads.
  • Use NVR Selector to quickly find a suitable model based on your requirements.
  • The number of streams that can be viewed simultaneously is twice the suggested maximum number of cameras. For example, if the suggested maximum number of cameras for a model is 10 under H.264, 1080p, the model can support up to 20 streams of the same specification at the same time.
Recommended Number of Concurrent Sync Clients350 (the number of connections that can be maintained when the recommended number of hosted files was reached)
 Recommended Number of Hosted Files5,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
 Notes
  • Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
  • Utilizing SSD cache can significantly improve performance.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.
Suggested Users3,000
 Notes
  • Suggested users is derived from testing in an environment with 60% idle users (each logging in and viewing documents) and 40% active users (each executing random actions at intervals of 20 to 40 seconds) operating within documents, each document having 30 users. Learn more
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Maximum Connections40
